Combined with the optional ASV+ quick adjustment, this model offers uncompromising precision at long distances, to allow a perfect shot at any distance.
Reticle 60. The extremely thin but also suitable for daytime light spot complements the reticle and convinces with its high intensity. Finely adjustable to meet every need, it is suitable for every hunting situation. From its position on the second image plane, it offers minimal target coverage – at 12x magnification only 0.55cm at 100m.
With the new ASV+ quick adjustment, the reticle can be set even easier and faster. The directly displayed distance makes ASV the most intuitive and precise long-range aiming concept ever. Thanks to the complete set of 10 metal rings, the new ASV+ quick adjustment is truly versatile. Virtually all charge trajectories available on the market are considered in the most precise way, to offer reliable aiming distances in hunting up to 600 meters. The new ASV+ rapid adjustment (the + distinguishes the new ones from the current ones), is available as an option, not before July.
With mounting rail (M).
TECHNICAL DATA SHEET
Magnifications 3-12x
Central tube diameter 30 mm
Adjustment range 100 m 120 cm
Objective diameter 44 - 56 mm
Exit pupil diameter 15 - 5 mm
Twilight value 8.5 - 25.9
Field of view at 100 m 12.5 - 3.5 m
Click adjustment at 100 m 1 cm
Reticles 60
Reticle image plane 2°
Parallax-free distance 100 m
Eye relief 90 mm
Nitrogen filling yes
Watertightness 400 mbar
Operating temperature -25/+50 °C
Objective bell diameter 56 mm
Eyepiece tube diameter 42 mm
Diopter adjustment range +2/-4 dpt
With rail yes
Net weight 598 g
Length 347 mm
Model VICTORY
Warranty duration 10
