Vudu 3.5-18x50 Ffp M-rad rifle scope - EOTECH

The VUDU 3.5-18x50 riflescope with 34mm tube was created for medium and long range shooting, the turrets are equipped with Zero Stop for easy adjustment even with poor visibility and with a total excursion of 29MRAD, furthermore the turrets are oversized to have more sensitivity during adjustment. The lenses are made of high density CX glass. The MRAD reticle is on the first focal plane.











Magnification

3.5-18x



Objective Lens

50mm



Focal Plane

First Focal Plane


Eye Relief

3.5x: 91-101mm; 18x: 90-101mm



Exit Pupil

3.5x: 11.2mm; 18x: 2.8mm



Field-Of-View (Degrees)

3.5x: 5.6 degrees; 18x: 1.1 degrees



Field-Of-View (@100 Yards)

3.5x: 29.5 ft; 18x: 5.7 ft



Exterior Finish

Flat Black; Type III anodized



Illumination Controls

Push Buttons



Exposed Optical Surface Treatment Lens Coating

Broadband anti-reflection coating



Windage and Elevation Increment Per Click

MD1, H59 Models: Approx. 0.1 MRAD

MD2 Model: Approx. 0.25 MOA





*EOTECH recommends removing battery from product during storage. In sleep mode, the battery draws slight current. Battery life during sleep mode is approx. 1,500 hours at room temperature.



Total Elevation Adjustment Range About Factory-Defined Zero Reference

± 14.5 min MRAD or ± 50 MOA



Total Windage Adjustment Range About Factory-Defined Zero Reference

± 11.5 min MRAD or ± 40 MOA



Battery Type

CR2032



Auto Power Shut-Off, Typical Time Interval at Which Power Will Shut Down to Preserve Battery Life

Approx. 2 hrs



Battery Life, Typical Time of Use at Room Temperature

Approx. 500 hrs at middle brightness setting 5*



Overall Length

377 mm (14.84 in)



Weight

33.6 oz (952 gr)



Tube Diameter

34mm
